Bomford Tri-Wing Flex Mower
The Tri-Wing flex mower, specifically designed for large open spaces, with wide-angle constant velocity drive shafts and in-line slip clutch protection.
The clean lines of this robust design, reduces the build up cut debris from collecting and rotting the machine deck, maximising its working life.
Wheel Equipment
Fitted with six 200/60 – 14.5 10 ply tyres as standard, the Tri-Wing 4.6 and 6m can also be also supplied with an eight wheel option for reduced ground pressure. The sprung shock absorbing mechanism ensures a smooth ride and reduces stress within the mainframe.
Features Include:
- 4.6m and 6m cutting widths
- Walking wheel kit option
- Nine heavy duty updraft blades
- Choice of 5 blade configurations
- Shredder option for maize
- Sprung suspension system
- 2.3m and 2.6m transport widths
- Hydraulic level lift system
Specifications
Photos
Video
Specifications
| MODELS | TW4600 | TW6000 |
| Cutting Width | 4.60m / 15′ | 6.0m / 20′ |
| Overall Width | 4.75m / 15’7″ | 6.30m / 20’8″ |
| Overall Length | 4.47m / 14’8″ | 5.15m / 16’11” |
| Transport Width | 2.34m / 7’8″ | 2.60m / 8’6″ |
| Cutting Height | 25mm – 375mm / 1″-15″ | 25mm – 375mm / 1″-15″ |
| Horsepower (Min) | 80hp | 100hp |
| Blade Overlap | 150mm / 6″ | 150mm / 6″ |
| PTO Speed | 1000 | 1000 |
| Wing Flex (Degrees) | 90° up -22° down | 90° up -22° down |
| Weight (Approx) | 2420kg / 5335lbs | 3470kg / 7650lbs |
