Spearhead Multicut 620
Spearhead Multicut 620 Rotary Mower
The Spearhead Multicut 620 is boosted with additional output capability, enabling the comfortable clearance of more than 8 hectares per hour.
A walking axle design is standard across the full width of the machine delivering exceptional ground contour following and reduced shock loading in harsh field conditions.
Wider wheels are also fitted to add additional comfort and improved performance.
Spearhead’s renowned durability is built into this mower and the evenness of spread from the five rotors is unrivalled leaving a clean finish and high output unmatched by competitive three rotor machines of the same width.
With a six gearbox driveline, each with slip clutch protection, the power is evenly spread to deliver exceptional reliability and durability whilst allowing enhanced forward speeds and fuel efficiency.
Spearhead Multicut 620 Features:
- 6.20 metre cutting width.
- 90hp minimum tractor power requirement.
- Heavy duty 250hp input gearbox.
- Heavy duty 165hp rotor gearboxes.
- Slip clutch protection.
- 8 pneumatic rear wheels.
- Anti-scalp rotor protection dishes.
- 15 x heavy duty cutting blades (3 per rotor).
- Floating wings.
- Rear lighting kit.
| TECHNICAL DATA | MULTICUT 620 |
| Cutting Width | 6.28m (20ft 7in) |
| Overall Width | 6.47m (21ft 3in) |
| Transport Width | 2.70m (8ft 11in) |
| Machine Weight* | 2850kg / 6283lbs |
| Gearbox Rating | 250hp and 165hp |
| Cutting Height | 25mm – 400mm (1in – 16in) |
| Number of Rotors | 5 |
| Number of Blades | 15 |
| PTO Protection | Slip Clutch |
| PTO Speed | 1000rpm |
| Tractor Power Required** | 90hp |
| *Dependent on machine specification **Dependent on conditions | |
