Wingmaxx Loader
Metal Pless Wingmaxx Loader
Maxximize the versatility, maneuverability, durability and affordability of a Wingmaxx system.
Metal Pless Wingmaxx Loader Features:
- A snow plow system that mounts to several brand sizes of wheel loaders.
- Increase loader utilization all winter to plow snow.
- Quick Tatch design for easy on and off of the front blade and side wing.
- Includes joystick control system.
- Optional LIVE EDGE multi section mechanical trip edge "reduces salt use by up to 50%".
Metal Pless Wingmaxx Loader Features:
- Front Blade 12' X 42".
- Side Wing (8' 9' 10' x 36") with deflector and SOFT DRIVE or LIVE EDGE trip edge.
- Adjustable angulation of the blade.
- Lateral floating of the blade.
- Skidshoes mounted to the back of the cutting edge.
- Front blade deflector.
- Baked powder coat paint.
Specifications
Opctions
Photos
Video
Specifications
| Specifications | WING12-08 | WING12-09 | WING12-10 |
| FRONT BLADE | |||
| Width | 12′ | 12′ | 12′ |
| Height | 42″ | 42″ | 42″ |
| SIDE WING | |||
| Width | 8′ | 9′ | 10′ |
| Height | 36″ | 36″ | 36″ |
| Application | 150 HP and up | 175 HP and up | 175 HP and up |
| Approx. Weight | 3600 lbs | 3750 lbs | 3900 lbs |
| The width of the blade does not determine the real dimension of the product. | |||
Opctions
Available Metal Pless Wingmaxx Options:
- Carbide cutting edge.
- Non standard colour.
- Nitrogen accumulator package installed on the up and down cylinder.
- Electric valve and Joystick (electric over hydraulic 4 spools mounted on the blade with electric control and necessary cable for the installation in the cab).
