Spartan Hook Lift Pro Plus
Spartan Hook Lift Pro Plus Features:
- Safety interlock system on intake nozzle.
- 40 gallon fuel tank.
- 30" balanced fan.
- Trans fluid coupler.
- 14,000 lb 3" adjustable pintle eye with safety chain.
- 74hp Kubota V3800 Tier 4 diesel-powered, liquid cooled engine.
- Direct wired engine control and joystick in truck cab.
- 20 yard collection body with full tailgate.
- Post compensated proportional hydraulic valve controls.
- Body up proximity switch.
- Hook lift skid assembly (does not include truck portion).
- DOT compliant lighting, markings, yellow flashers.
- 12 volt electrical system.
- Packer style rear door with hydraulic latch.
Specifications
Options
Photos
Specifications
| TECHNICAL DATA | SPARTAN HOOK LIFT PRO PLUS |
| Empty Weight: | 8400 lbs |
| Full Weight | 16,400 lbs |
| Fuel Tank, Aluminum | 40 U.S. Gallons |
| Engine | 74 h.p. Kubota V3800 Tier 4 |
| Collection Nozzles | Right Side |
| Battery | 12 Volt, 1190 Amp; 950 CCA |
| Fan | 30″ Diameter |
Options
Spartan Hook Lift Pro Plus Options:
- Directional light bar / L.E.D. flashers.
- 74 h.p. Kohler 2504 Tier 4.
- 99 h.p. John Deere Tier 4.
- 120 h.p. Kohler 3404 Tier 4.
Photos
